Additional information
| Mounting | |
|---|---|
| Size | M, L |
| Light Source | LED |
| Voltage | 220-240 V, 50-60 Hz |
| Net Lumen Output (at Ta=25°C) | 5750 lm, 6100 lm, 6400 lm, 6800 lm, 7800 lm, 8250 lm, 8900 lm, 9450 lm |
| Power Consumption | |
| System Efficacy | 151-166 lm/W |
| CRI | |
| CCT | |
| Colour Tolerance | |
| Light Distribution | |
| Optical System | DIRECT: lenses + black louver (LBL), INDIRECT: Transparent diffuser |
| Beam Angle (C0-180, C90-270) | 90° |
| Wiring | |
| Power Factor | 0.97 |
| Materials | Housing: sheet steel, Lenses: PMMA, Louvre: polycarbonate |
| Accessories | Rope suspension RS-S 58 |
| Surface Finish | Housing: white RAL 9003 (W03) |
| Service Lifetime (Ta 25°C) | 100,000 hours/L80/B10 |
| Ambient Operating Temp. | |
| Protection Class | I |
| Protection Degree | |
| On Request | White louvre (LWL), Asymmetric, Beam angle 65°, Emergency unit variant (3H) |
| Notice | Suspension is not included, it must be ordered separately. |
