Additional information
| Mounting | |
|---|---|
| Size | M, L |
| Light Source | LED |
| Voltage | 220-240 V, 50-60 Hz |
| Net Lumen Output (at Ta=25°C) | 5200 lm, 5200 lm – EM 100 lm, 5500 lm, 5500 lm – EM 110 lm, 5900 lm, 5900 lm – EM 100 lm, 6200 lm, 6200 lm – EM 110 lm |
| Power Consumption | |
| System Efficacy | 140-149 lm/W |
| CRI | |
| CCT | |
| Colour Tolerance | |
| Light Distribution | |
| Optical System | |
| Beam Angle (C0-180, C90-270) | 75°, 85° |
| Wiring | FIX (ECG), DALI (EDA), Emergency unit variant (3H, ECG), External lead-in flexible cable |
| Power Factor | >0.95 |
| Materials | Housing: sheet steel, Diffuser: PMMA |
| Surface Finish | Housing: white RAL 9003 (W03) |
| Accessories | Rope suspension RS-S 58 |
| Service Lifetime (Ta 25°C) | 100,000 hours/L90/B10 |
| Ambient Operating Temp. | |
| Protection Class | I |
| Protection Degree |
