Additional information
Mounting | |
---|---|
Size | M, L |
Light Source | LED |
Voltage | 220-240 V, 50-60 Hz |
Net Lumen Output (at Ta=25°C) | 3100 lm, 3100 lm – EM 490 lm, 3250 lm, 3250 lm – EM 520 lm, 3300 lm, 3300 lm – EM 490 lm, 3450 lm, 3450 lm – EM 520 lm, 3900 lm, 3900 lm – EM 490 lm, 4050 lm, 4050 lm – EM 520 lm, 4100 lm, 4100 lm – 490 lm, 4300 lm, 4300 lm – EM 520 lm, 4350 lm, 4350 lm – EM 490 lm, 4500 lm, 4500 lm – EM 520 lm, 5200 lm, 5200 lm – EM 490 lm, 5450 lm, 5450 lm – EM 520 lm, 5500 lm, 5500 lm – EM 490 lm, 5800 lm, 5800 lm – EM 520 lm |
Power Consumption | |
System Efficacy | 132-159 lm/W |
CRI | |
CCT | |
Colour Tolerance | |
Light Distribution | |
Optical System | |
Beam Angle (C0-180, C90-270) | 80° |
Wiring | |
Power Factor | 0.97 |
Materials | Housing: sheet steel, Louvre: polycarbonate |
Surface Finish | Housing: white RAL 9003 (W03) |
Accessories | Rope suspension RS-S 58 |
Service Lifetime (Ta 25°C) | 100,000 hours/L80/B10 |
Ambient Operating Temp. | |
Protection Class | I |
Protection Degree |
