Additional information
| Mounting | |
|---|---|
| Light Source | LED |
| Voltage | 220-240 V, 50-60 Hz |
| Net Lumen Output (at Ta=25°C) | 1600 lm, 1700 lm, 2700 lm, 2800 lm, 3900 lm, 4100 lm, 4950 lm, 5200 lm, 6100 lm, 6400 lm, 6850 lm, 7200 lm, 8350 lm, 8750 lm |
| Power Consumption Initial | 10 W, 17 W, 25 W, 33 W, 41 W, 48 W, 55 W |
| Power Consumption End | 11 W, 18 W, 27 W, 35 W, 43 W, 50 W, 58 W |
| System Efficacy | 143-170 lm/W |
| CRI | |
| CCT | |
| Colour Tolerance | |
| Windage Area Side/Top | 0.094/0.125 m2 |
| Light Distribution | |
| Optical System | |
| Wiring | FIX + CONSTANT LUMEN OUTPUT (ECC), DALI + CONSTANT LUMEN OUTPUT (EDO), INT DIM + CONSTANT LUMEN OUTPUT (EPO), External lead-in flexible cable |
| Power Factor | 0.98 |
| Materials | Housing: die cast aluminium, Cover: transparent hardened glass, Tiltable spigot: die-cast aluminium |
| Surface Finish | Housing: grey RAL 9006 (G06) |
| Service Lifetime (Ta 25°C) | 100,000 hours/L100/B10 |
| Ambient Operating Temp. | |
| Protection Class | II |
| Protection Degree | |
| On Request | Lenses L02, L03, L04, L05, L06, L08, L09, L10, L11, L12, L18, Protection class I |
